Evidence-Based Medicine – Hierarchy of Evidence and Types of Research

Evidence-based medicine (EBM) is the integration of the best available research evidence with clinical expertise and patient values and preferences to make informed healthcare decisions.

EBM does not mean following published evidence blindly. High-quality care requires interpretation of research in the context of the individual patient, the clinical setting, available resources, potential harms and expected benefits.

Evidence-based medicine is not “cookbook medicine” — evidence must be critically appraised and applied to the right patient.

A commonly used framework is the 5 A's of evidence-based practice.

1. Ask: formulate a focused and answerable clinical question.
2. Acquire: search for the best available evidence.
3. Appraise: critically evaluate validity, importance and applicability.
4. Apply: integrate the evidence with clinical expertise and patient preferences.
5. Assess: evaluate the outcome and the effectiveness of the decision-making process.

Clinical questions are often structured using the PICO framework.

Time or study design may sometimes be added, giving frameworks such as PICOT or PICOS.

The “best” study design depends on the clinical question being asked.

Clinical research can broadly be divided into:

• Primary research: investigators collect or analyse original patient-level or experimental data.
• Secondary research: investigators synthesise or interpret existing studies.
• Quantitative research: uses numerical measurements and statistical analysis.
• Qualitative research: explores experiences, beliefs, perceptions and behaviours.
• Mixed-methods research: combines quantitative and qualitative approaches.

Descriptive studies describe the occurrence, presentation or characteristics of disease without necessarily testing a causal hypothesis.

Case Report

A detailed description of an individual patient with an unusual diagnosis, presentation, treatment response or complication.

Case reports are useful for generating hypotheses and identifying rare or unexpected events but cannot establish treatment effectiveness or causality.

Case Series

A case series describes a group of patients with a similar disease, intervention or outcome. There is usually no comparison group.

Case series are particularly common in surgical research but are highly vulnerable to selection bias and confounding.

A cross-sectional study measures exposure and outcome in a population at a particular point or short period in time.

It is commonly used to estimate prevalence.

Advantages

• Relatively quick.
• Usually inexpensive.
• Useful for describing disease burden.
• Can evaluate multiple variables simultaneously.

Limitations

• Temporal relationship between exposure and outcome may be unclear.
• Generally cannot establish causality.

A case-control study begins with the outcome.

Patients with the disease or outcome of interest are identified as cases, and patients without the outcome are selected as controls. Previous exposure is then compared between the two groups.

Case-control study: start with disease → look backward for exposure.

Best Uses

• Rare diseases.
• Outcomes with long latency periods.
• Investigation of multiple potential exposures.

Major Limitations

• Recall bias.
• Selection bias.
• Confounding.
• Direct incidence cannot usually be calculated.

The common measure of association in a case-control study is the odds ratio (OR).

Conceptually: Odds ratio = ad / bc

• OR = 1: no association.
• OR > 1: exposure associated with greater odds of outcome.
• OR < 1: exposure may be protective.

A cohort study begins with exposure status.

Exposed and unexposed groups are followed or reconstructed over time to compare the occurrence of an outcome.

Cohort study: start with exposure → observe subsequent outcome.

Types

• Prospective cohort: subjects are followed forward from the time of enrolment.
• Retrospective cohort: existing records are used to reconstruct exposure and outcomes that have already occurred.

Advantages

• Can calculate incidence.
• Temporal sequence is usually clearer than in cross-sectional studies.
• Can study multiple outcomes from one exposure.

Limitations

• Confounding.
• Loss to follow-up.
• Can be expensive and time consuming if prospective.
• Inefficient for very rare outcomes.

The relative risk (RR), or risk ratio, compares the risk of an outcome between an exposed or treated group and a comparison group.

Conceptually:

RR = Risk in exposed group / Risk in unexposed group

• RR = 1: no difference in risk.
• RR > 1: higher risk in the exposed group.
• RR < 1: lower risk in the exposed group.

In a randomised controlled trial (RCT), eligible participants are randomly allocated to different interventions or control groups and outcomes are compared.

Randomisation aims to distribute known and unknown prognostic factors between treatment groups, thereby reducing confounding.

For therapeutic interventions, a well-conducted RCT is generally the strongest individual primary study design for estimating causal treatment effects.

Randomisation

Randomisation refers to assigning participants to intervention groups using an unpredictable random sequence.

Allocation Concealment

Allocation concealment prevents the person enrolling participants from knowing the upcoming treatment assignment.

It protects against selection bias.

Allocation concealment is different from blinding.

Blinding means keeping one or more individuals unaware of treatment allocation after participants have been assigned.

Depending on the study, blinding may involve:

• Participants.
• Treating clinicians.
• Outcome assessors.
• Data analysts.

Blinding is often difficult or impossible in orthopaedic surgical trials, but blinded outcome assessment may still reduce bias.

In an intention-to-treat (ITT) analysis, participants are analysed according to the group to which they were originally randomised, regardless of crossover, non-compliance or protocol deviation.

ITT helps preserve the benefits of randomisation and usually provides an estimate of the effect of assigning a treatment strategy in real clinical practice.

Diagnostic studies evaluate the ability of an index test to identify a target condition compared with an accepted reference standard.

Sensitivity

Sensitivity is the proportion of patients with the disease who have a positive test.

Sensitivity = TP / (TP + FN)

Specificity

Specificity is the proportion of patients without the disease who have a negative test.

Specificity = TN / (TN + FP)

Highly sensitive tests are useful for reducing missed disease when negative, while highly specific tests are useful for supporting a diagnosis when positive, although interpretation should consider the entire clinical context and likelihood ratios.

Positive Predictive Value

Probability that a patient with a positive test actually has the disease.

PPV = TP / (TP + FP)

Negative Predictive Value

Probability that a patient with a negative test truly does not have the disease.

NPV = TN / (TN + FN)

Unlike sensitivity and specificity, predictive values are strongly influenced by disease prevalence in the tested population.

Likelihood ratios describe how much a test result changes the probability of disease.

Positive likelihood ratio: Sensitivity / (1 − Specificity)

Negative likelihood ratio: (1 − Sensitivity) / Specificity

Larger positive likelihood ratios and smaller negative likelihood ratios provide greater diagnostic information.

Qualitative research explores experiences, perceptions, beliefs and behaviour rather than primarily measuring numerical outcomes.

Common methods include:

• Individual interviews.
• Focus groups.
• Participant observation.
• Document or thematic analysis.

Qualitative research can be particularly valuable for understanding patient experiences, barriers to treatment, rehabilitation adherence and shared decision-making.

A systematic review uses a predefined and reproducible methodology to identify, select, critically appraise and synthesise all relevant studies addressing a focused research question.

Important components include:

• Focused research question.
• Predefined inclusion and exclusion criteria.
• Comprehensive literature search.
• Transparent study selection.
• Risk-of-bias assessment.
• Structured evidence synthesis.

A systematic review may or may not include a meta-analysis.

Meta-analysis is a statistical technique used to combine quantitative results from multiple sufficiently similar studies to estimate an overall treatment or exposure effect.

Potential advantages include increased statistical precision and improved estimation of treatment effects.

However, the reliability of a meta-analysis depends on the quality and comparability of the included studies.

A meta-analysis of poor-quality studies does not automatically become high-quality evidence.

Heterogeneity refers to differences between studies included in a systematic review.

Clinical Heterogeneity

Differences in patients, interventions, outcomes or settings.

Methodological Heterogeneity

Differences in study design, risk of bias or measurement methods.

Statistical Heterogeneity

Variation in effect estimates beyond that expected from sampling error alone.

The I² statistic is commonly used to describe statistical heterogeneity, but it should not be interpreted without considering the clinical and methodological differences between studies.

A forest plot graphically displays the results of individual studies and the pooled estimate in a meta-analysis.

• The square usually represents the effect estimate from an individual study.
• The size of the square generally reflects the study's statistical weight.
• The horizontal line represents the confidence interval.
• The diamond commonly represents the pooled estimate.
• The vertical line represents the line of no effect.

Publication bias occurs when the probability of a study being published is influenced by the nature or direction of its results, often favouring statistically significant or apparently positive findings.

A funnel plot may be used in meta-analysis to explore possible small-study effects and publication bias when a sufficient number of studies are available.

Funnel-plot asymmetry is not specific for publication bias and may have other explanations.

A hierarchy of evidence ranks study designs according to their usual ability to minimise bias and support reliable clinical conclusions.

This hierarchy is a useful general guide, but it is not absolute. The appropriate hierarchy differs according to whether the question concerns therapy, diagnosis, prognosis, harm or patient experience.

Study design alone does not determine evidence quality — a poorly performed RCT may provide less reliable evidence than a well-conducted observational study.

Several organisations use formal levels-of-evidence systems. Exact definitions differ between organisations and according to the clinical question.

A simplified therapeutic hierarchy often resembles:

The exact scheme being used should always be stated because one organisation's “Level II” may not be identical to another's.

Clinical practice guidelines are systematically developed recommendations intended to assist clinicians and patients in making decisions about appropriate healthcare.

A high-quality guideline should:

• Use a systematic evidence search.
• Evaluate the quality or certainty of evidence.
• Consider benefits and harms.
• Consider patient preferences and feasibility.
• Declare conflicts of interest.
• Clearly link recommendations to evidence.

The GRADE approach is widely used to assess the certainty of evidence for specific outcomes and to support clinical guideline recommendations.

Certainty is commonly classified as:

• High.
• Moderate.
• Low.
• Very low.

Evidence may be downgraded because of:

• Risk of bias.
• Inconsistency.
• Indirectness.
• Imprecision.
• Publication bias.

Bias is a systematic error that causes an estimated association or treatment effect to differ from the truth.

A confounder is a factor associated with both the exposure and the outcome that can distort the apparent relationship between them.

For example, if patients receiving one surgical procedure are systematically younger and healthier than those receiving another procedure, age and general health may confound the relationship between procedure and outcome.

Methods used to reduce confounding include:

• Randomisation.
• Restriction.
• Matching.
• Stratification.
• Multivariable statistical adjustment.
• Propensity-score methods in selected observational studies.

A very large study can still give a highly precise but biased answer.

Internal Validity

Internal validity refers to whether the study's result is likely to be correct for the participants who were actually studied.

External Validity

External validity, or generalisability, refers to whether the findings can reasonably be applied to other patients, populations and clinical settings.

A tightly controlled trial may have excellent internal validity while having limited generalisability to routine clinical practice.

The p value is the probability, under the assumptions of the statistical model and null hypothesis, of observing data at least as incompatible with the null hypothesis as the data actually observed.

Conventionally, a threshold such as p < 0.05 is often used to define statistical significance, although this threshold is arbitrary and should not be interpreted as proof of clinical importance or truth.

Statistical significance does not necessarily mean clinical significance.

A confidence interval provides a range of values compatible with the observed data under the statistical model and indicates the precision of an effect estimate.

Narrow confidence intervals indicate greater precision, while wide intervals indicate greater uncertainty.

For relative measures such as RR or OR, a confidence interval crossing 1 includes the null value. For an absolute difference, the null value is usually 0.

Absolute effects are often more clinically intuitive than relative effects.

Absolute Risk Reduction (ARR) is the difference in event risk between control and treatment groups.

ARR = Control Event Rate − Experimental Event Rate

Number Needed to Treat (NNT) = 1 / ARR

ARR must be expressed as a proportion rather than a percentage when calculating NNT.

Suppose fixation failure occurs in:

• 20% of the control group.
• 10% of the treatment group.

ARR = 0.20 − 0.10 = 0.10

NNT = 1 / 0.10 = 10

Therefore, approximately 10 patients would need to receive the treatment rather than control to prevent one additional fixation failure over the specified follow-up period, assuming the estimate is valid and applicable.

When an intervention increases the absolute risk of an adverse event, the reciprocal of the absolute risk increase can be expressed as the Number Needed to Harm (NNH).

NNT and NNH should always be interpreted together with the follow-up period and baseline risk.

A difference can be statistically significant while being too small to matter to the patient.

Conversely, a potentially clinically important difference may fail to achieve statistical significance if the study is too small or imprecise.

Clinical interpretation should therefore consider:

• Magnitude of effect.
• Confidence interval.
• Patient-important outcomes.
• Baseline risk.
• Potential harms.
• Cost and burden of intervention.

The minimal clinically important difference (MCID) refers broadly to the smallest change in an outcome considered meaningful to patients or clinically important.

MCID is particularly useful when interpreting patient-reported outcome measures, pain scales and functional scores.

A statistically significant improvement smaller than the clinically meaningful threshold may have limited practical relevance.

• Alpha (α) relates to the tolerated probability of a Type I error.
• Beta (β) relates to the probability of a Type II error.
• Power = 1 − β.

Statistical power is the probability that a study will detect a specified true effect when that effect exists, under the assumptions used for the calculation.

Power generally increases with:

• Larger sample size.
• Larger true effect size.
• Lower variability.
• Higher accepted Type I error threshold.

An underpowered study may fail to identify a genuine clinically important difference.

Registries and large administrative databases allow investigators to study outcomes in large real-world patient populations.

Advantages

• Large sample sizes.
• Ability to study uncommon outcomes.
• Good representation of routine clinical practice.

Limitations

• Confounding.
• Missing data.
• Variable data quality.
• Coding errors.
• Lack of detailed clinical variables.

Basic science research investigates fundamental biological or mechanical processes and may include laboratory, cellular, biomechanical and animal studies.

Translational research attempts to move discoveries from fundamental science toward clinically useful applications and, conversely, use clinical observations to generate scientific questions.

Basic science is essential for understanding mechanisms, but mechanistic plausibility alone does not establish that a treatment improves clinically important patient outcomes.

Patient-Important Outcomes

• Pain.
• Function.
• Quality of life.
• Return to work or sport.
• Reoperation.
• Complications.
• Mortality.

Surrogate Outcomes

Surrogate outcomes are substitute measurements expected to predict clinically meaningful outcomes. Examples in orthopaedics may include certain radiographic measurements, biomarkers or intermediate measures of healing.

Surrogate improvement does not always translate into better patient-important outcomes.

Critical appraisal can be simplified into three major questions:

• Was the randomisation truly random?
• Was allocation adequately concealed?
• Were important baseline characteristics similar?
• Were participants and outcome assessors blinded where feasible?
• Was follow-up sufficiently complete?
• Were participants analysed in their assigned groups?
• Were co-interventions similar between groups?
• Were clinically important outcomes measured?
• What was the magnitude of benefit or harm?
• How precise was the estimate?
• Are the results applicable to my patient?

• How were participants selected?
• Were exposure and outcome measured reliably?
• Was the comparison group appropriate?
• Could selection bias explain the findings?
• What important confounders were present?
• How were confounders adjusted?
• Was follow-up adequate?
• Was there missing data?
• Is the effect large enough to be clinically meaningful?
• Can causality reasonably be inferred?

Observational research can demonstrate an association between an exposure and an outcome, but the observed relationship may be due to:

• True causation.
• Chance.
• Bias.
• Confounding.
• Reverse causation.

Stronger causal inference requires consideration of study design, temporality, consistency, biological plausibility and alternative explanations.

Orthopaedic research presents several specific difficulties.

• Blinding surgeons is often impossible.
• Surgical expertise varies between operators.
• Implant technology changes rapidly.
• Fracture patterns and patient populations are heterogeneous.
• Surgeon treatment preference can cause selection bias.
• Learning curves may affect outcomes.
• Rare complications require very large sample sizes.
• Crossovers between treatment groups may occur.
• Radiographic outcomes may not correlate perfectly with patient-reported function.

These limitations make careful interpretation of both randomised and high-quality observational studies especially important in orthopaedic practice.

• Evidence-based medicine combines research evidence, clinical expertise and patient preferences.
• PICO = Patient, Intervention, Comparison, Outcome.
• Case-control studies begin with disease/outcome and look for previous exposure.
• Cohort studies begin with exposure and evaluate subsequent outcomes.
• Odds ratio is classically associated with case-control studies.
• Relative risk can be directly calculated in cohort studies and RCTs when risks are observed.
• Cross-sectional studies are particularly useful for estimating prevalence.
• Randomisation primarily helps reduce confounding by distributing prognostic factors between groups.
• Allocation concealment prevents foreknowledge of upcoming treatment assignment and reduces selection bias.
• Blinding occurs after allocation and helps reduce performance and detection biases.
• Intention-to-treat analysis preserves the main advantages of randomisation.
• Sensitivity = TP / (TP + FN).
• Specificity = TN / (TN + FP).
• PPV and NPV depend strongly on disease prevalence.
• A systematic review does not necessarily contain a meta-analysis.
• A meta-analysis is a statistical pooling technique.
• A poor-quality RCT does not automatically provide better evidence than a high-quality observational study.
• Type I error = false-positive conclusion.
• Type II error = false-negative conclusion.
• Statistical significance does not necessarily equal clinical significance.
• NNT = 1 / absolute risk reduction.
• Internal validity concerns whether the result is valid within the study; external validity concerns generalisability.
• Bias is systematic error and cannot simply be eliminated by increasing sample size.
• Association alone does not prove causation.

1. Ask the right question: structure the clinical uncertainty using PICO.
2. Choose the right evidence: the ideal study design depends on whether the question concerns therapy, diagnosis, prognosis or harm.
3. Understand the hierarchy: systematic reviews and RCTs often provide strong therapeutic evidence, but study quality remains crucial.
4. Recognise observational designs: case-control studies start with outcome; cohort studies start with exposure.
5. Look beyond the p value: examine effect size, confidence interval, absolute risk and clinical relevance.
6. Search for bias and confounding: these can substantially distort apparently convincing results.
7. Assess applicability: determine whether the participants, intervention and clinical setting resemble the patient in front of you.
8. Integrate evidence rather than obey it: research findings must be combined with clinical expertise and patient preferences.

The purpose of evidence-based medicine is not simply to find the highest-level paper. It is to identify the most trustworthy evidence for the clinical question, understand its limitations and apply it appropriately to the individual patient.
