Tscherne–Oestern — Closed Fracture Soft-Tissue Injury

Overview — Why Soft Tissue Assessment Matters in Closed Fractures

The assessment of soft tissue injury in closed fractures is critically important yet frequently underappreciated. A closed fracture of the tibia — by definition, with intact overlying skin — can nonetheless cause profound soft tissue damage from internal mechanisms: haematoma formation, muscle crush, swelling, compartment pressure rise, and progressive skin necrosis from within. The degree of soft tissue injury is an independent determinant of fracture healing, infection risk (particularly after internal fixation), complication rates, and the safety of early surgical intervention. The Tscherne-Oestern classification (1982) was the first systematic attempt to grade the soft tissue injury associated with CLOSED fractures, and it remains the most clinically useful system for communicating and documenting the internal soft tissue environment in closed fractures.

Historical context: Tscherne and Oestern published their classification in 1982 (Unfallchirurgie) as part of a broader system that also included a grading for open fractures (the Tscherne-Oestern open fracture classification is a parallel but distinct system, less widely used than the Gustilo-Anderson system); the closed fracture component of the Tscherne-Oestern classification has remained in use as the standard for closed soft tissue documentation; it was developed from experience with tibia fractures in particular, but applies to all closed long bone fractures
Why the soft tissue grade of a closed fracture matters: (1) timing of surgery — a Grade C0/C1 closed tibia fracture can be operatively stabilised early (within 24–48 hours); a Grade C2/C3 fracture with extensive soft tissue swelling and blisters should be delayed (7–14 days) until the soft tissues have settled and the risk of wound breakdown is reduced; (2) risk of post-operative wound complications — opening a severely swollen, blistered limb risks infection and wound necrosis; (3) the internal soft tissue environment — Grade C3 injuries with muscle crush and potential compartment syndrome require fasciotomy at the time of fixation; (4) the soft tissue injury score contributes to overall injury severity and prognosis

Tscherne-Oestern Classification — Closed Fractures (C Grades)

Grade	Skin	Muscle & Deeper Soft Tissue	Fracture Type	Clinical Significance & Management
C0 — Minimal	No skin injury; intact; minimal swelling; normal turgor	No muscle injury; no deep soft tissue damage; haematoma minimal	Simple, low-energy fracture pattern (torsional spiral, simple transverse); indirect mechanism; minimal energy imparted to the soft tissues	Excellent soft tissue environment; early surgical fixation is safe (within 24 hours); lowest infection risk after fixation; best prognosis for wound healing; example: a simple spiral tibial shaft fracture from a low-energy sporting injury in a young adult
C1 — Superficial abrasion or contusion	Superficial abrasion over the fracture; or a contusion of the skin from within by the bone fragment (internal contusion from bone spike pressing against the skin from within — the `punch` sign); the skin is intact but is contused; moderate swelling	Superficial muscle bruising; no deep muscle injury; mild haematoma	Mild to moderately comminuted fracture; moderate-energy mechanism; the overlying skin has been damaged by the bone end pressing against it from within	Mild soft tissue compromise; early fixation is usually safe if the skin contusion is small and the abrasion is superficial; avoid incisions through the contused/abraded skin; modify the surgical approach to avoid the injured skin; example: a bending tibial fracture with a skin contusion directly over the fracture where the bone spiked the skin internally
C2 — Deep, contaminated abrasion or severe skin contusion; blister formation	Deep contaminated abrasion; OR skin blistering from the internal haematoma pressure (tension blisters or fracture blisters — filled with clear fluid [serum blisters] or with blood [blood blisters]); significant swelling; the skin is compromised but intact; blistering indicates significant internal pressure and soft tissue compromise; fracture blisters are a clinical sign of severe internal soft tissue injury	Moderate muscle damage; deep haematoma; significant internal soft tissue compromise from the fracture energy and swelling; the deep tissues are significantly injured even though the skin is intact	Comminuted, moderately high-energy fracture; significant displacement; the energy has been sufficient to cause deep soft tissue destruction and blistering	DELAY surgery until soft tissues settle (typically 5–14 days); DO NOT operate through blistered skin (risk of wound breakdown and infection); management of blisters: clear (serous) blisters — aspirate the fluid, leave the blister roof intact as a biological dressing; blood-filled blisters — associated with deeper dermal injury, have a worse prognosis; wait until the blisters have de-roofed and re-epithelialised before surgery; temporary external fixation (ExFix) provides fracture stability while waiting for soft tissues to improve
C3 — Extensive crush, degloving, or compartment syndrome	Extensive skin contusion and impending necrosis; subcutaneous degloving (the skin has been sheared from the deep fascia — creating a potential space filled with haematoma — `Morel-Lavallée lesion`); OR established/impending compartment syndrome; OR skin on the verge of necrosis (visible venous congestion, mottled appearance, impaired capillary refill over the fracture)	Severe muscle crushing; compartment syndrome (elevated compartment pressures → muscle ischaemia → necrosis without fasciotomy); extensive haematoma and muscle necrosis	High-energy mechanism (road traffic accidents, crush injuries); highly comminuted or segmental fracture; the fracture is almost secondary to the soft tissue emergency	URGENT management of the soft tissue emergency; if compartment syndrome is present → 4-compartment fasciotomy is MANDATORY and takes priority; fasciotomy + fracture stabilisation (ExFix) as the acute management; definitive fracture fixation after soft tissues have stabilised; extensive NPWT for the fasciotomy wounds; the wounds are left open and managed with serial debridements; requires experienced multidisciplinary management; prognosis guarded for wound healing, infection, and ultimate fracture union

Fracture Blisters — Management Detail

Fracture blisters: occur at Tscherne Grade C2; they form when severe haematoma pressure from within the soft tissues causes a separation at the dermal-epidermal junction; the blister cavity fills with serum (clear blister) or blood (blood blister); the depth of the epidermal-dermal separation determines the type: clear blisters (serum) = separation at the superficial dermal papillae = better prognosis; blood blisters = separation deeper in the dermis (full-thickness dermal injury) = worse prognosis; presence of fracture blisters is an absolute contraindication to immediate ORIF through the blistered area
Management algorithm: (1) do NOT aspirate blood blisters (blood blister roof = the only remaining dermis — its removal exposes dermis-free skin that heals poorly and is highly infection-prone); (2) aspirate clear blisters (leave the roof intact — it provides biological coverage); (3) apply non-adherent dressing (Mepitel or similar); (4) elevate the limb; (5) apply temporary ExFix for fracture stability; (6) wait for blisters to fully de-roof and re-epithelialise (typically 10–21 days); (7) plan ORIF when the skin is healed and the swelling has reduced

Tscherne-Oestern Open Fracture Classification

For completeness, the Tscherne-Oestern open fracture classification (IO grades) is presented alongside the closed fracture grades. While less universally used than the Gustilo-Anderson system, it forms the complete Tscherne-Oestern system and is occasionally referenced in European literature.

Grade	Description	Equivalent Gustilo Type
IO1	Low-energy wound from within (<1 cm); minimal contamination; simple fracture	~Gustilo Type I
IO2	Wound from without; skin and muscle contused; moderate contamination; moderate comminution	~Gustilo Type II
IO3	Extensive skin loss; crushed skin and muscle; highly comminuted fracture; highly contaminated; adequate soft tissue coverage possible	~Gustilo Type IIIA
IO4	Neurovascular injury requiring repair; massively contaminated; degloving; bone exposure requiring flap	~Gustilo Type IIIB/IIIC

Exam Pearls

Tscherne-Oestern Closed (C grades): C0 (minimal — early fixation safe); C1 (superficial abrasion/internal contusion — early fixation usually safe, avoid incision through contusion); C2 (blisters, deep abrasion — DELAY 5–14 days); C3 (crush, degloving, compartment syndrome — fasciotomy urgent, ExFix, delay ORIF)
Fracture blisters = Grade C2: clear blisters = better prognosis; blood blisters = deeper dermal injury = worse; aspirate clear blisters (leave roof); do NOT aspirate blood blisters (leave roof as biological coverage); no ORIF through blistered skin
Grade C3 compartment syndrome: this is the acute emergency within the Tscherne system; 4-compartment fasciotomy is mandatory before or at the time of fracture stabilisation; ExFix provides stability; leave wounds open; NPWT; definitive fixation after soft tissues stabilise
Timing of ORIF after closed fracture: C0/C1 = early (within 24–48 hours); C2 = delay 5–14 days (wait for blisters to re-epithelialise); C3 = fasciotomy acutely + ExFix; ORIF after soft tissues settle
Morel-Lavallée lesion: a closed degloving injury — the skin is sheared off the deep fascia by a tangential force (e.g., run-over by a vehicle); the cavity fills with haematoma and eventually with debris; classified as Tscherne C3; managed by thorough cavity debridement and careful monitoring; if infected → surgical exploration and debridement
The Tscherne classification complements the AO fracture classification: in European surgical documentation, both the bony fracture AO type AND the Tscherne soft tissue grade are recorded together for completeness (e.g., `42-A2/C2` = tibial shaft simple transverse fracture with blister formation)
Clinical application: when a patient with a tibial shaft fracture has tense blisters and severe swelling → Tscherne C2; apply spanning ExFix, elevate the limb, aspirate clear blisters, apply Mepitel dressing; plan ORIF in 10–14 days when skin is re-epithelialised; do NOT proceed to immediate nailing through the blistered area
